| Display Feature |
LCD |
15″ LCD |
| Resolution |
1024*768 |
| Brightness |
300 cd/m2 |
| Contrast |
1500:1 |
| Screen |
5-wires resistive touch screen |
| Performance |
Chipset |
Intel®Core 6th I3/I5/I7 |
| Memory |
4GB DDR3 RAM, Max 8 GB |
| Hardware monitor |
Voltage and CPU temperature monitor |
| Watch dog |
255 levels timer interval,setup by software |
| Storage |
SSD、HDD |
| Power |
Power supply |
9-24V DC IN, Or 9-36V DC IN optional |
16W（standby）
30.6W（rate power） |
| OS |
OS |
Windows 7/8/10、Linux |
| I/O |
USB |
4*USB3.0 |
| COM |
4*RS232，1*RS422/485 optional |
| Lan |
2* Intel I211 RJ45 GbE |
| Audio |
1*Line out + 1* MIC |
| Display |
1*VGA +1*HDMI |
| Environment |
Anti-vbration |
5-19Hz/1.0mm amplitude;19-200Hz/1.0g acceleration |
| Anti-shock |
acceleration10g/11ms duration |
| IP level |
Front IP 65 optional |
| Reliability |
MTBF≥50000h; MTTR≤0.5h |
| Operating temperature： |
-10℃～50℃ with air flow |
| Storage temperature |
-20℃～60℃ |
| Operating humidity： |
95% @40℃, non-condensing |
| Mechanical |
Dimension |
380mm (L)*300mm(W)*59mm(H) |
| Material |
Aluminum alloyed fanless design |
| Weight |
5.2kg/6.8kg(N.T/G.W) |
| Color |
Silver/White/Black |
